Referential Integrity Options

Referential integrity rules vary depending on:

• Whether or not the entity is a parent or child in the relationship
• The database action that is implemented

As a result, in each relationship there are six possible actions for which referential integrity can be defined:

• PARENT INSERT
• PARENT UPDATE
• PARENT DELETE
• CHILD INSERT
• CHILD UPDATE
• CHILD DELETE

The following figure shows referential integrity rules in the EMPLOYEE‑PROJECT model:

The referential integrity rules captured in the figure show the business decision to cascade all deletions in the PROJECT entity to the PROJECT-EMPLOYEE entity. This rule is called PARENT DELETE CASCADE, and is noted in the figure by the letters D:C placed at the parent end of the specified relationship. The first letter in the referential integrity symbol always refers to the database action: I(Insert), U(Update), or D(Delete). The second letter refers to the referential integrity option: C(Cascade), R(Restrict), SN(Set Null), and SD(Set Default).

In the figure, no referential integrity option was specified for PARENT INSERT, so referential integrity for insert (I:) is not displayed on the diagram.
